NILES-SIMMONS N20 MC Turn-Mill
The NILES-SIMMONS N20 MC Turn-Mill is a precision multi-axis, multifunction turning-boring-milling machining center for work pieces up to 3500 mm in length.
The CNC control system is a SINUMERIK ONE, with Siemens NX Programming and Support supplied in partnership with Empire Dynamics.
The NILES-SIMMONS N20 MC Turn-Mills are the optimal solution for complex part machining operations. The MC-Series utilize one set-up / “closed door machining” to eliminate the need for multiple machining centers, decrease production time, and increase output and safety.
Machine Specifications
Download our NILES-SIMMONS N20 MC product data sheet — for the full machine specification, please contact the Machine Sales team.
Maximum Swing Diameter
650 mm
Turning Length Range
1000-3500 mm
Number of Tools per Unit (Range)
60-120
Spindle Type
A8 | A11
Spindle Speed Range
0-3800 rpm
Maximum Spindle Drive Power
36 kW
Slide Travel (X-Axis)
675 mm
Slide Travel (Y-Axis)
350 mm
Tool Systems
HSK 63T | Capto C6*
*optional systems
Maximum Driving Power
33 kW
Speed Range
0-10000 rpm
Maximum Torque Milling Spindle
250 Nm
